The Task Support Vehicle combines the best of elevating work platforms, order pickers and tuggers in one compact vehicle. Built as an alternative to rolling ladders and larger equipment, it handles everything from overhead maintenance to order picking. It can raise an operator up to 192" off the floor, turn around in as little as 72", and be driven at height to move from task to task. A high-efficiency AC drive motor, programmable from the onboard LCD dash, provides travel. Power comes from a 224 Ah maintenance-free AGM battery pack that opportunity-charges from a standard 120V outlet, or an industrial battery and external charger (required on the J1-192). Patented design (US D730,614, D733,389, D733,390, 9,440,830).
Get Pricing
Request a quote
Rent, buy or lease — tell us what you need to move.
Features
Built for all-day duty
Up to 1,000 lb total vehicle capacity: 500 lb front tray, 300 lb operator, 200 lb rear tray*
LCD dash with selectable travel settings and diagnostics
Electronic power steering with infinitely variable speed control
Fingertip controls integrated into retractable guardrails
Premium steel I-beam mast and unitized steel frame
180° articulating driveline with 72" minimum turn radius
*Consult factory for capacity derate on J1-162 and J1-192.
Specifications
Technical data
| Vehicle Type | Task Support Vehicle |
|---|---|
| Max Capacity | 1,000 lb (500 front / 300 operator / 200 rear) |
| Power | 24V AC electric, Zapi transistor control |
| Max Platform Height | 126" / 162" / 192" |
| Collapsed Height | 62.6" / 82.75" / 83.25" |
| Battery | 224 Ah AGM pack / industrial (required on J1-192) |
| Charger | Integral 120V in pack / industrial (required on J1-192) |
| Vehicle Dimensions | See product information sheet |
